Bayonet Type Connection

The connection of the CODE 7 filter to the base of the housing is made by a quarter turn, ensuring a quick and safe installation.

Design Pressure and Temperature

The filter housing is designed to withstand a pressure of -1/ 3 barg and a temperature of up to 150°C, meeting the most demanding industry standards.

Regulatory Compliance

Manufactured according to ASME VIII Div.1 design code, our housings guarantee maximum quality and safety in every application.

High Quality Materials

Vent housings are manufactured from ASTM A182 F-316 and ASTM A240 316L stainless steel for product contact parts, ensuring exceptional corrosion resistance and optimum durability.

Customization Options

We offer the possibility of manufacturing the housings in other materials to meet any specific customer requirements.

Finishes

The internal roughness of the parts in contact with the product complies with ASME BPE SF1 RA≤0.5µm standards, while the exterior finish of the housing is pharmaceutical satin, with an average roughness Ra≤0.8µm. In addition, our filter housings feature EPDM CLAMP connection gaskets, although we also offer other material options such as PTFE.
